EGB36100 - Square D 100A 600Y/347V 3-Pole E-Frame Bolt-On Circuit Breaker

EGB36100

EGB36100 is a 100 amp, 3-pole, 600Y/347 volt AC bolt-on circuit breaker from Square D's EGB Series.This molded case circuit breaker features thermal magnetic trip protection with a trip unit rating of 875 amps and an interrupt rating of 18 kA at 600Y/347 V AC. It is designed for use in Square D NF panelboards and supports aluminum and copper lug connections. The breaker is UL and CSA certified and suitable for HID and HACR applications.

• Amperage: 100A
• Voltage: 600Y/347 V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18 kA
• Series/Frame: EGB E-Frame
• Trip Unit: Thermal Magnetic, 875 Amp rating
• Connection: Aluminum and Copper Lugs
• Application: HID-Rated, HACR-Rated
• Certifications: UL, CSA
• Dimensions: 5.66" x 2.94" x 4.05"
• Weight: 4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB36100
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : G; E-Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901234845
• GTIN : 00785901234845
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.739
• Panel Type : NF panelboard
• Standards : cULus
• Certification : cULus
• Wire Size : AWG 12 to AWG 2/0, Aluminum, AWG 14 to AWG 2/0, Copper
