Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
EGB36090
EGB36090 is a Square D 3 pole bolt-on circuit breaker rated for 90 amps and 600Y/347 volts AC with a thermal-magnetic trip unit.
This molded case circuit breaker features an E-frame design suitable for branch circuit protection. It provides reliable interruption with an 18kA interrupt rating at 600 volts and includes a signal indicator for trip status. The bolt-on mounting type ensures secure installation in compatible panels.
- Manufacturer: Square D
- Part Number: EGB36090
- Amperage: 90A
- Voltage Rating: 600Y/347 VAC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 18kA @ 600V
- Frame/Series: E-Frame
- Trip Unit: Thermal-Magnetic
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: EGB36090
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : EGB Series
- Type : EGB
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Temp Rating : 104 °F (40 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 078590140673
- GTIN : 00785901406730
- Country of Origin : Mexico
- Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
- Weight : 3.48
- Panel Type : NF panelboard
- Certification : cULus
- Wire Size : AWG 12...AWG 2/0 aluminum
AWG 14...AWG 2/0 copper
