EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic

Save $644.44
SKU: EGB36060-New
Condition: New
Price:
$486.56 $1,131.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EGB36060 - Square D Bolt-On 480V 60A 3 pole circuit breaker 35kA@480V - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EGB36060 - Square D Bolt-On 480V 60A 3 pole circuit breaker 35kA@480V - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply
EGB36060 - Square D 60A 600Y/347V 3-Pole Molded Case Circuit Breaker Bolt-On E-Frame Thermal Magnetic - Essential Electric Supply

Description

EGB36060


EGB36060 is a 60 Amp, 3 Pole molded case circuit breaker from Square D designed for bolt-on mounting in NF panelboards.This Square D EGB series breaker features a thermal magnetic trip unit with a trip range of 630 to 1800 Amps, suitable for 600Y/347 Volt AC applications. It has an interrupt rating of 65 kA at 240 VAC and 35 kA at 480 VAC, and is constructed with a durable thermoset composite resin housing. The breaker supports aluminum lug connections for wire sizes from 14 to 2/0 AWG aluminum or copper and is rated for 50/60 Hz operation.
    Key Specifications
    • Amperage: 60 A
    • Voltage Rating: 600Y/347 VAC
    • Number of Poles: 3
    • Mounting Type: Bolt-On
    • Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC
    • Frame: E-Frame (EGB Series)
    • Trip Unit: Thermal Magnetic
    • Wire Size Range: 14 to 2/0 AWG Al/Cu
    • Connection Type: Aluminum Lugs
    • Phase: 3
    • Dimensions: 5.66" x 2.94" x 4.05"
    • Certifications: UL Listed (US and Canada)
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Specifications

    • Part Number: EGB36060
    • Manufacturer : Schneider Electric
    • Brand : Square D
    • Category : Circuit Breaker
    • Item Subcategory : Molded Case
    • Family : EGB Series
    • Type : EGB
    • Voltage : 480
    • Amperage : 60
    • Phase : 3
    • Poles : 3
    • AIC rating : 35kA@480V
    • Connection : Bolt-On
    • Functions : Long Time and Instantaneous Trip
    • Terminal Connection : Lug
    • Frame Size : G; E-Frame
    • Temp Rating : -13–158 °F (-25–70 °C)
    • MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG (Cu/Al)
    • Protection : Thermal Magnetic

    Product Data

    • UPC : 785901264323
    • GTIN : 00785901264323
    • Country of Origin : Mexico
    • Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
    • Weight : 3.549
    • Panel Type : NF panelboard
    • Standards : cULus
    • Certification : cULus
    • Wire Size : AWG 12 to 2/0 Aluminum, AWG 14 to 2/0 Copper
