EGB36050 - Square D EGB 50A 3 Pole 600Y/347VAC Circuit Breaker 65kA/35kA Interrupt

EGB36050

EGB36050 is a Square D EGB series molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This 3 pole, 50 amp circuit breaker features a 600Y/347VAC voltage rating and is equipped with a thermal/magnetic trip unit for overload and short-circuit protection. The EGB36050 is a bolt-on mounting type, suitable for use in panelboards and switchgear applications. It offers an interrupt rating of 65kA at 240VAC and 35kA at 480Y/277VAC, ensuring robust performance under fault conditions.

• Part Number: EGB36050
• Manufacturer: Square D
• Series/Frame: EGB
• Amperage: 50A
• Number of Poles: 3
• Voltage Rating: 600Y/347VAC
• Interrupt Rating: 65kA @ 240VAC, 35kA @ 480Y/277VAC
• Mounting Type: Bolt-On
• Protection Type: Thermal/Magnetic Trip
• Application: Commercial/Industrial Power Distribution
• Certification: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB36050
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 480
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901235576
• GTIN : 00785901235576
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.64
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
