EGB3100FFB - Cutler Hammer G Series 3-Pole 100A 480V Molded Case Circuit Breaker 18kAIC

EGB3100FFB

EGB3100FFB is a three-pole, 100A, 480V molded case circuit breaker from the Cutler Hammer G Series, designed for reliable protection in commercial and industrial applications.Engineered with a fixed thermal and fixed magnetic trip unit, this breaker features bolt-on mounting and a 18kAIC interrupt rating at 480V. Suitable for use in three-phase systems, it offers long time and instantaneous trip functions with non-interchangeable trip settings. The breaker includes line and load side lug terminals for easy installation and is rated for 50/60 Hz operation.

• Part Number: EGB3100FFB
• Manufacturer: Cutler Hammer (Eaton)
• Series: G Series
• Frame: EG
• Poles: 3
• Amperage: 100A
• Voltage: 480V AC
• Interrupt Rating: 18kAIC @ 480V
• Mounting: Bolt-on
• Terminals: Line & Load Side Lug
• Frequency: 50/60 Hz
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Certifications: UL 489, CE, CSA, IEC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB3100FFB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGB
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685381664
• GTIN : 00786685381664
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 2.91
• Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
