EGB14040EPD - Square D 40A 1P 277V E-Frame Bolt-On Ground Fault Circuit Breaker, 35kAIC, Thermal Magnetic Trip

EGB14040EPD

EGB14040EPD is a Square D 1-pole, 40A, 277VAC miniature circuit breaker with ground fault protection, designed for equipment protection in commercial and industrial applications.

This E-Frame, bolt-on circuit breaker features a thermal magnetic trip unit, long time and instantaneous trip functions, and a high interrupting capacity of 35kAIC at 480V. It is suitable for use in panelboards and switchboards requiring reliable ground fault protection.

Key Specifications
• Amperage: 40A
• Voltage: 277VAC
• Poles: 1
• Mounting Type: Bolt-on
• Interrupt Rating: 35kAIC at 480V
• Series/Frame: EGB (E-Frame)
• Trip Unit: Thermal Magnetic
• Ground Fault Protection: 30mA
• Certifications: Not specified in available data
• Equipment Protection Device
• Long Time and Instantaneous Trip Functions
• High Interrupting Capacity

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB14040EPD
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 277
• Amperage : 40
• Phase : 1
• Poles : 1
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901982227
• GTIN : 00785901982227
• Country of Origin : Mexico
• Dimensions : 6.64 in (168.66 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.1
• Certification : CULus
• Wire Size : AWG 14 to AWG 6, AWG 12 to AWG 4, Cu/Al
