Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDS3150BP10
EDS3150BP10 is a 150 Amp, 3-pole molded case circuit breaker from Eaton's Series C, F-frame lineup designed for reliable circuit protection.This Eaton circuit breaker features a fixed thermal, fixed magnetic trip unit providing consistent protection at 240 Vac and 125 Vdc. It has a 65 kA interrupt rating at 240 Vac, suitable for demanding electrical applications. The breaker is a complete unit with load side terminals and is UL Listed for safety and compliance.
- Key Specifications
- Amperage Rating: 150 A
- Voltage Rating: 240 Vac, 125 Vdc
- Number of Poles: Three-pole
- Frame Type: F-frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 65 kA at 240 Vac
- Mounting Type: Load side terminals (bolt-on)
- Certifications: UL Listed
- Frequency Rating: 50/60 Hz
- Part Number: EDS3150BP10
- Manufacturer : Eaton
- Brand : Culter Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDS
- Voltage : 240
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 42kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- Weight : 4
