EDH2100W - Eaton 100A 2-Pole 240V AC 125V DC Molded Case Circuit Breaker F-Frame Thermal Magnetic

EDH2100W

EDH2100W is a 2-pole molded case circuit breaker from Eaton's Series C with a 100 ampere rating and thermal magnetic trip type.

This breaker is designed for use at 240 volts AC and 125 volts DC, featuring a bolt-on mounting type and an interrupt rating of 100kA at 240 VAC. It belongs to the F-frame style and provides reliable protection with a fixed magnetic trip unit (T186). The EDH2100W is UL listed and suitable for a variety of industrial and commercial applications requiring robust circuit protection.

• Amperage: 100 A
• Voltage Rating: 240 VAC, 125 VDC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 100 kAIC at 240 VAC
• Series/Frame: Eaton Series C, F-Frame
• Trip Unit: Thermal Magnetic (T186)
• Type: EDH Molded Case Circuit Breaker
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: EDH2100W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 100
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 078667945686
• GTIN : 00786679456866
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
