Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDH2175Y
EDH2175Y is an Eaton Series C complete molded case circuit breaker designed for reliable thermal magnetic protection in industrial and commercial applications. This two-pole breaker features fixed thermal magnetic trip technology with an F-frame configuration and line and load terminals for flexible installation options.
- Amperage Rating: 175 A
- Voltage Rating: 240 Vac, 125 Vdc
- Number of Poles: 2
- Circuit Breaker Type: ED
- Series: Series C
- Frame Type: F-Frame
- Trip Type: T186 Fixed Thermal Magnetic
- Interrupt Rating: 100 kAIC at 240 Vac
- Frequency Rating: 50 to 60 Hz
- Terminals: Line and Load
- Certifications: UL Listed
- Dimensions: 2.75 in W x 3.38 in D x 6 in H
Specifications
- Part Number: EDH2175Y
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDH
- Voltage : 240
- Amperage : 175
- Phase : 2
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679455944
- GTIN : 00786679455944
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
