EDH2175W - Eaton Series C 175A 2-Pole Molded Case Circuit Breaker 100kAIC 240V

EDH2175W

EDH2175W is a Series C molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This breaker features a robust construction and is engineered for high interrupt capacity and dependable performance. The EDH2175W is a two-pole, 175A molded case circuit breaker with a thermal magnetic trip unit. It is rated for 240 Vac and 125 Vdc, and offers an interrupt rating of 100kA at 240 Vac. The breaker is part of Eaton's Series C line and is designed for use in standard panelboard and switchgear applications.

• Amperage Rating: 175 A
• Voltage Rating: 240 Vac, 125 Vdc
• Number of Poles: Two-pole
• Interrupt Rating: 100kA at 240 Vac
• Series: Series C
• Frame Type: F-frame
• Mounting Type: Busbar (No Lugs)
• Line and Load Terminals
• Frequency Rating: 50 to 60 Hz
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: EDH2175W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 175
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456682
• GTIN : 00786679456682
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
