EDH2150Y - Eaton Series C F-Frame 2-Pole 150A 240VAC Molded Case Circuit Breaker

EDH2150Y

EDH2150Y is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications. This F-frame, 2-pole breaker features fixed thermal and fixed magnetic trip units, delivering consistent performance at 150 amperes with dual voltage ratings of 240 Vac and 125 Vdc. The line-side termination uses lugs for secure connections, while the load-side connects via busbar integration. With an interrupt rating of 100 kA at 240 Vac, this breaker handles high fault currents safely and efficiently across 50/60 Hz systems. Key Specifications

• Part Number: EDH2150Y
• Manufacturer: Eaton
• Series: Series C
• Frame Type: F-Frame
• Poles: 2
• Amperage Rating: 150A
• Voltage Rating: 240 Vac / 125 Vdc
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupt Rating: 100 kA @ 240 Vac
• Frequency: 50/60 Hz
• Line Termination: Lugs
• Load Termination: Busbar
• Certification: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2150Y
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 150
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456002
• GTIN : 00786679456002
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
