EDH2125Y - Eaton Series C Molded Case Circuit Breaker 2-Pole 125A 240VAC 125VDC 100kA Interrupt F-Frame

EDH2125Y

EDH2125Y is a Series C molded case circuit breaker from Eaton, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a robust F-frame construction and is engineered for 2-pole operation with a 125A current rating and 100kA interrupt capacity at 240VAC. The EDH2125Y is built for fixed thermal and fixed magnetic trip functionality, ensuring consistent performance under varying load conditions. It is suitable for panel mounting and features line side lugs for secure connections. The breaker is compatible with standard 240VAC and 125VDC systems, making it versatile for a range of applications.

• Part Number: EDH2125Y
• Manufacturer: Eaton
• Series/Frame: Series C, F-Frame
• Poles: 2
• Amperage: 125A
• Voltage: 240VAC, 125VDC
• Interrupt Rating: 100kA @ 240VAC
• Mounting Type: Panel
• Terminal Method: Line Side Lugs
• Trip Unit: Fixed Thermal/Fixed Magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2125Y
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 125
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456064
• GTIN : 00786679456064
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
