Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDC2150Y
EDC2150Y is a Series C molded case circuit breaker designed for reliable protection in commercial and industrial applications. This F-frame breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overcurrent protection for two-pole circuits. The EDC2150Y is rated for 150 amps at 240 volts AC and 125 volts DC, with an interrupt rating of 200kA at 240VAC. It is suitable for use in load-side applications and is UL listed for safety and compliance. The breaker is designed for bolt-on mounting and is part of Eaton's Series C product line.
- Series C molded case circuit breaker
- F-frame construction
- Two-pole configuration
- 150A amperage rating
- 240VAC, 125VDC voltage rating
- 200kAIC interrupt rating at 240VAC
- Fixed thermal, fixed magnetic trip type
- Bolt-on mounting
- UL listed
- Load-side application
- 50/60 Hz frequency rating
- Complete breaker assembly
Specifications
- Part Number: EDC2150Y
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDC
- Voltage : 240
- Amperage : 150
- Phase : 2
- Poles : 2
- AIC rating : 200kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679456026
- GTIN : 00786679456026
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
