EDB36070 - Schneider Electric Square D EDB Series 70A 3-Pole 600Y/347V AC Bolt-On Miniature Circuit Breaker, E-Frame, 14kA Interrupt, HACR, UL Listed

EDB36070

EDB36070 - Schneider Electric E-Frame molded case circuit breaker, 70A, 3-pole, bolt-on mounting for NF panelboards.The EDB36070 features thermal-magnetic trip protection for overload and short-circuit, with Visi-Trip indicator for easy troubleshooting. Rated at 600Y/347 VAC, it includes aluminum lugs accepting AWG 12-6 aluminum or AWG 14-6 copper wire, calibrated for 40C operation, and designed for lighting panelboard applications.

• Part Number: EDB36070
• Manufacturer: Schneider Electric
• Amperage: 70A
• Voltage: 600Y/347 VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 14 kA at 600Y/347 VAC
• Series/Frame: EDB / E-Frame
• Trip Unit: Thermal-Magnetic
• Frequency: 50/60 Hz
• Wire Range: AWG 14-6 Cu / 12-6 Al
• Certifications: UL Listed, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB36070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : D; E-Frame
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901407010
• GTIN : 00785901407010
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.549
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12 to AWG 2/0, AWG 14 to AWG 2/0, Aluminum/Copper
