EDB36050 - Square D 50 Amp 600V 3-Pole Bolt-On Molded Case Circuit Breaker EDB Series

EDB36050

EDB36050 is a 3-pole, 50 Amp, 600 Volt Bolt-On molded case circuit breaker from Square D's EDB Series designed for reliable thermal magnetic protection.This circuit breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions, suitable for 3-phase systems. It has a 14kA interrupting rating at 600Y/347 V AC and is UL and cUL listed. The breaker is designed for Bolt-On mounting with aluminum lug connections and is compatible with Square D NF panelboards.

Key Specifications
• Amperage: 50 Amp
• Voltage: 600Y/347 V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 14kA at 600Y/347 V AC
• Series/Frame: EDB
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous) functions
• Connection Type: Aluminum Lugs
• Phase: 3
• Dimensions (HxWxD): 5.66" x 2.94" x 4.05"
• Certifications: UL and cUL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EDB36050
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : D; E-Frame
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901234807
• GTIN : 00785901234807
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.501
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12, AWG 2/0 Aluminium, AWG 14, AWG 2/0 Copper
