EDB36045 - Square D 45A 600V 3-Pole Thermal Magnetic Circuit Breaker Bolt-On

EDB36045

EDB36045 is a 45 Amp, 600 Volt, 3-Pole thermal magnetic circuit breaker from Square D designed for Bolt-On installation.

This Square D EDB series circuit breaker provides superior overload and short circuit protection with a 125 A frame. It is suitable for use in lighting panelboards and features a thermal magnetic trip unit. The breaker has interrupt ratings of 25 kA at 240 VAC, 18 kA at 480Y/277 VAC, and 14 kA at 600Y/347 VAC. It is UL listed for use in the US and Canada.

• Amperage: 45 Amp
• Voltage Rating: 600Y/347 VAC
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 14 kA @ 600Y/347 VAC
• Interrupt Rating: 18 kA @ 480Y/277 VAC
• Interrupt Rating: 25 kA @ 240 VAC
• Frame/Series: 125 A Frame EDB
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed (US and Canada)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB36045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : D; E-Frame
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901406747
• GTIN : 00785901406747
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.651
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
