EDB36040 - Square D 40A 600Y/347V 3-Pole Molded Case Circuit Breaker E-Frame Bolt-On

EDB36040

EDB36040 - Schneider Electric E-Frame 3-pole molded case circuit breaker rated 40A 600Y/347V AC with thermal-magnetic trip and bolt-on mounting. This EDB Series breaker provides thermal-magnetic protection for short-circuit and overload with 14kA interrupting capacity at 600Y/347V AC, trip indicator, and aluminum/copper lugs compatible with AWG 12-6 aluminum or AWG 14-6 copper. Calibrated for 40 degrees C, it suits HID-rated and HACR-rated applications in Square D NF panelboards.

• Part Number: EDB36040
• Manufacturer: Schneider Electric
• Series/Frame: EDB / E-Frame
• Poles: 3
• Amperage: 40A
• Voltage: 600Y/347V AC
• Mounting Type: Bolt-On
• Trip Unit: Thermal-Magnetic
• Interrupt Rating: 14kA @ 600Y/347V AC
• Functions: Long-Time and Instantaneous (LI)
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB36040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : D; E-Frame
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901234302
• GTIN : 00785901234302
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.549
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12 to AWG 2/0, AWG 14 to AWG 2/0, Aluminum/Copper
