EDB36030 - Square D 30A 600V 3-Pole EDB Series Bolt-On Thermal Magnetic Circuit Breaker

EDB36030

EDB36030 is a 3-pole, 30 amp, 600 volt Bolt-On molded case circuit breaker from Square D's EDB Series designed for reliable circuit protection.This thermal magnetic circuit breaker features long-time and instantaneous trip functions, a 14 kA interrupt rating at 600Y/347 V AC, and is suitable for HID and HACR applications. It mounts Bolt-On and is compatible with Square D NF panelboards, providing short-circuit and overload protection with aluminum lug connections.

• Amperage: 30A
• Voltage: 600Y/347 V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 14 kA at 600Y/347 V AC
• Series/Frame: EDB
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Certifications: UL Listed (Canada and US)
• Application: HID-Rated / HACR-Rated
• Connection: Aluminum Lugs
• Dimensions: 5.66" x 2.94" x 4.05"
• Weight: 4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB36030
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : D; E-Frame
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901233961
• GTIN : 00785901233961
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.7
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12, AWG 6 Aluminium, AWG 14, AWG 6 Copper
