EDB36025 - Square D 25A 600V 3-Pole E-Frame Circuit Breaker Bolt-On Thermal Magnetic

EDB36025

EDB36025 - Schneider Electric E-Frame miniature circuit breaker, 25A, 3 pole, rated for 600Y/347VAC with bolt-on mounting for lighting panelboards.This EDB36025 breaker provides superior overload and short circuit protection in Square D NF panelboards. It features a thermal-magnetic trip unit, E-Frame design, and is calibrated for 40 degrees C operation. The bolt-on mounting ensures secure installation in branch circuit applications.

• Part Number: EDB36025
• Manufacturer: Schneider Electric
• Type: E-Frame Miniature Circuit Breaker
• Amperage: 25A
• Poles: 3
• Voltage: 600Y/347 VAC
• Mounting: Bolt-On
• Interrupt Rating: 25kA@240VAC, 18kA@480Y/277VAC, 14kA@600Y/347VAC
• Trip Unit: Thermal-Magnetic
• Frame: E-Frame (125A max)
• Certifications: UL, CSA, HACR rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB36025
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901234869
• GTIN : 00785901234869
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.7
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12...AWG 6 aluminum
  AWG 14...AWG 6 copper
