Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
EDB34030LH
EDB34030LH is a Schneider Electric E-Frame miniature circuit breaker rated at 30A, 3 poles, and 480Y/277V AC with thermal-magnetic trip unit.This bolt-on circuit breaker features high ampere aluminum lugs for secure connections (AWG 14-6) and provides superior overload and short-circuit protection for lighting panelboards and NF panelboards. It offers interrupting ratings of 25kA at 120/240VAC and 18kA at 480Y/277VAC, with a trip indicator for local signaling.
- Part Number: EDB34030LH
- Manufacturer: Schneider Electric
- Amperage: 30A
- Voltage: 480Y/277V AC
- Poles: 3
- Frame: E-Frame
- Mounting Type: Bolt-on
- Trip Unit: Thermal-magnetic
- Interrupting Rating: 25kA @ 120/240VAC, 18kA @ 480Y/277VAC
- Connection: High ampere aluminum lugs (AWG 14-6)
- Product Type: Miniature circuit breaker
Specifications
- Part Number: EDB34030LH
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : EDB Series
- Type : EDB
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Temp Rating : 104 ¡F (40 ¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 785901589136
- GTIN : 00785901589136
- Country of Origin : Mexico
- Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
- Weight : 3.46
- Standards : cULus, IEC
- Certification : cULus, IEC
