EDB34020LH - Square D 20A 480Y/277V 3-Pole Miniature Circuit Breaker E-Frame Bolt-On

EDB34020LH

EDB34020LH is a Square D 20 Amp, 3-Pole Miniature Circuit Breaker designed for 480Y/277 Volt AC applications with Bolt-On mounting.This thermal magnetic circuit breaker from the E-Frame series features a 3-pole design with an 18 kA interrupting rating at 480Y/277V, suitable for branch circuit protection in lighting panelboards. It includes high amp lugs and supports lug-type terminal connections, ensuring reliable overload and short circuit protection.

• Amperage: 20 A
• Voltage Rating: 480Y/277 V AC
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 18 kA at 480Y/277 V AC
• Series/Frame: E-Frame
• Trip Unit: Thermal Magnetic
• Terminal Connection: Lug
• Certifications: UL Listed (US and Canada)
• Application: Lighting Panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB34020LH
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901638582
• GTIN : 00785901638582
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.48
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
