ED63B060L - Siemens 3 Pole 60 Amp 600V Molded Case Circuit Breaker Thermal Magnetic Trip

ED63B060L

ED63B060L is a Siemens Sentron Series 3 Pole molded case circuit breaker with a 60 Amp current rating and 600V AC voltage rating, designed for reliable thermal magnetic protection in commercial and industrial applications. This Siemens ED63B060L circuit breaker features a bolt-on mounting style, standard interrupting capacity, and is suitable for use in 50/60 Hz systems. It is built for durability and safety, with a robust frame and feed-thru lug connections for easy installation.

• Part Number: ED63B060L
• Manufacturer: Siemens
• Series/Frame: Sentron Series, ED Frame
• Poles: 3 Pole
• Amperage: 60 Amps
• Voltage: 600V AC, 500V DC
• Interrupt Rating: 25kA @ 480V, 65kA @ 240V
• Mounting Type: Bolt-On
• Frequency Rating: 50/60 Hz
• Trip Unit: Thermal Magnetic
• Temperature Rating: 40¡C
• Standards: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED63B060L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : ED
• Voltage : 600 AC
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : ED Frame
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643236349
• GTIN : 00783643236349
• Country of Origin : Mexico
• Dimensions : 6.693 x 5.906 x 3.1001
• Weight : 3.799 lb
• Certification : Ul Listed, IEC
• Wire Size : AWG 10 to AWG 1/0, Cu/Al
