ED22B100 - Siemens Sentron ED22B100 100A 240V 2-Pole Molded Case Circuit Breaker, 10kA Interrupt, Bolt-On, Thermal/Magnetic Trip, ED Frame

ED22B100

ED22B100 is a Siemens Sentron series molded case circuit breaker designed for reliable low voltage circuit protection.

This 2-pole, 100A breaker operates at 240V AC and 125/250V DC, featuring a 10kA interrupting capacity, bolt-on mounting, and a thermal/magnetic trip unit. It is part of the ED frame series and is calibrated for standard 40°C applications, offering robust performance for commercial and industrial electrical systems.

Key Specifications

• Part Number: ED22B100
• Manufacturer: Siemens
• Series/Frame: Sentron, ED
• Amperage: 100A
• Voltage: 240V AC, 125/250V DC
• Poles: 2
• Mounting Type: Bolt-on
• Interrupt Rating: 10kA @ 240V
• Trip Unit: Thermal/magnetic
• Certifications: Standard IC rating
• Temperature Rating: 40°C
• Dimensions: 2" W x 6.35" H x 3.92" D
• Weight: 2.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED22B100
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : ED
• Voltage : 240
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Lug In Panelboard
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 125A/ED
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 10 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Any

Product Data

• UPC : 783643208957
• GTIN : 00783643208957
• Country of Origin : Mexico
• Dimensions : 2 in x 6.34 in
• Weight : 2.701
• Panel Type : SB Switchboards, Sentron Panelboards
• Standards : HACR Rated, UL Listed
• Certification : HACR Rated, UL Listed
• Wire Size : 10 To 1/0 AWG (Aluminum/Copper)
