ECN0501AAA - Cutler Hammer Eaton Freedom NEMA 1 Non-Combination Non-Reversing Motor Starter 110V/50-60Hz 3 Pole Size 0

ECN0501AAA

ECN0501AAA is a Cutler Hammer Eaton Freedom NEMA motor control starter designed for reliable motor starting and protection.This motor starter features a non-combination, non-reversing design with a NEMA 1 enclosure and NEMA size 0 frame. It operates on a coil voltage of 110V/50 Hz to 120V/60 Hz and supports three poles. The starter is UL Listed (file E1491) and suitable for industrial and commercial motor control applications. It includes a standard interchangeable heater overload relay and is built for durability and ease of installation.

• Manufacturer: Cutler Hammer Eaton
• Part Number: ECN0501AAA
• Type: Non-Combination Non-Reversing Motor Starter
• Coil Voltage: 110V/50 Hz - 120V/60 Hz
• Poles: 3 Pole
• Enclosure: NEMA 1
• Size: NEMA Size 0
• Interrupt Rating: Not specified
• Trip Unit: Standard interchangeable heater overload relay
• Certifications: UL Listed file E1491
• Dimensions: 11.6" L x 7.4" H x 7.6" W
• Weight: 5.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: ECN0501AAA
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Freedom Series
• Type : ECN05
• Voltage : 600
• Amperage : 18
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 110 VAC
• Coil Voltage Minimum : 120
• Nema Rating : 0
• Nema Starter Size : 0
• Enclosure : 1
• Compatible Frames : DK,KD,KDB,HKD,HKDB,KDC,CKD,CHKD
• Frequency : 50 Hz

Product Data

• UPC : 782114015797
• GTIN : 00782114015797
• Country of Origin : United States
• Dimensions : 11.6 in x 7.4 in x 7.6 in (Length/Depth x Height x Width)
• Weight : 5.5
• Certification : UL Listed file E1491
