Description
ECL03B1A4A
ECL03B1A4A is a Eaton CN35 electrically held lighting contactor designed for reliable motor control applications.This contactor features a 20 ampere current rating, 4 poles, and operates on a coil voltage of 110-120 VAC at 50/60 Hz. It has a NEMA 1 enclosure made of painted steel with a 45 mm frame size. The device includes a HAND/OFF/AUTO selector switch and is UL and cUL listed for safety and performance compliance.
- Amperage Rating: 20A
- Coil Voltage: 110-120 VAC, 50/60 Hz
- Number of Poles: 4 (Four-pole)
- Enclosure Type: NEMA 1
- Enclosure Material: Painted Steel
- Frame Size: 45 mm
- Series: A202 / CN35
- Contact Rating: 20 A
- Selector Switch: HAND/OFF/AUTO
- Certifications: UL Listed, cUL Listed
Specifications
- Part Number: ECL03B1A4A
- Manufacturer : Eaton
- Brand : Eaton
- Category : Motor Control
- Item Subcategory : Contactor
- Voltage : 3
- Compatible Frames : DK,KD,KDB,HKD,HKDB,KDC,CKD,CHKD
Product Data
- UPC : 782114152676
- GTIN : 00782114152676
- Country of Origin : United States
- Dimensions : 7.73 in x 12.6 in x 5.84 in (Length/Depth x Height x Width)
- Weight : 5.2
- Certification : OSHPD Certified,ABS Certified,cUL Listed,UL Listed
