E50AT3 - Cutler Hammer E50 Series Motor Control Limit Switch 10A 240V 1NO-1NC NEMA 1-13

E50AT3

E50AT3 is a Cutler Hammer E50 Series heavy-duty motor control limit switch designed for reliable industrial operation.This assembly features a top push roller actuator with spring return, screw terminal connections, and a contact configuration of 1 normally open and 1 normally closed contact. It supports a contact rating of 10A at 240 Vac and 1A at 250 Vdc. The enclosure is made of die cast zinc and rated for multiple NEMA environments including NEMA 1, 3, 3S, 4, 4X, 6, 6P, and 13, with an IP67 rating for dust and water resistance. Certified by UL, CSA, and CE, it operates reliably within a temperature range of 14°F to 201°F.

Key Specifications
• Manufacturer: Cutler Hammer
• Series: E50
• Contact Rating: 10A at 240 Vac, 1A at 250 Vdc
• Contact Configuration: 1 NO - 1 NC
• Actuator: Top push roller with spring return
• Connection Type: Screw terminal
• Enclosure Material: Die cast zinc
• Environmental Rating: NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13, IP67
• Certifications: UL Listed, CSA Certified, CE Marked
• Operating Temperature: 14°F to 201°F (-10°C to 121°C)
• Mounting: Plug-in assembly

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E50AT3
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Section : Limit Switch
• Family : E50 Series
• Type : E50AT

Product Data

• UPC : 782113308821
• GTIN : 00782113308821
• Country of Origin : Mexico
• Dimensions : 4.22 in x 2.25 in x 1.54 in (Length/Depth x Height x Width)
• Weight : 1.1 lb
• Certification : CE, CSA, UL
