CVS2200X3MM - Cutler Hammer 200A 240V 2-Pole Molded Case Circuit Breaker Type CV 42kA Interrupt

CVS2200X3MM

CVS2200X3MM is a Cutler Hammer Type CV molded case circuit breaker designed for reliable electrical protection.This 2-pole circuit breaker is rated for 200 amps and 240 volts AC, featuring a thermal/magnetic trip unit for dependable overload and short circuit protection. It has a high interrupt rating of 42 kA at 240 VAC, suitable for demanding electrical environments. The breaker includes a mounting kit and supports conductor sizes from #6 to 4/0 aluminum or copper wire, with a maximum load of 300 kcmil. It is UL 489 and CSA certified, ensuring compliance with industry safety standards.

Key Specifications
• Amperage: 200 A
• Voltage: 240 VAC
• Poles: 2
• Interrupt Rating: 42 kA at 240 VAC
• Trip Unit: Thermal/Magnetic
• Series/Frame: Type CV
• Mounting Type: Panel mount
• Wire Range: #6 - 4/0 Al/Cu
• Maximum Load: 300 kcmil
• Certifications: UL 489, CSA C22.2 No. 5
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CVS2200X3MM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVS Series
• Type : CVS
• Voltage : 240
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 78668570594
• GTIN : 00786685705941
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : CSA Std. C22.2 No. 5,UL 489
• Wire Size : 300 Kcmil
