CVS2100XMM - Cutler Hammer Eaton 100A 240V 2-Pole Molded Case Circuit Breaker Type CV 42kAIC Bolt-On

CVS2100XMM

CVS2100XMM is a Cutler Hammer Eaton 2-pole molded case circuit breaker rated for 100 amps and 240 volts AC with a 42 kA interrupt rating.This Type CV circuit breaker features thermal magnetic trip protection, bolt-on mounting, and supports #6 to 4/0 AWG copper or aluminum wire with a maximum load of #4/0 kcmil. It includes a mounting kit and meets UL 489 and CSA C22.2 No. 5 certifications.

Key Specifications
• Amperage: 100 A
• Voltage: 120/240 VAC
• Poles: Two-pole
• Interrupt Rating: 42 kAIC
• Mounting Type: Bolt-On
• Wire Size: #6 - 4/0 AWG Cu/Al
• Maximum Load: #4/0 kcmil
• Series/Frame: Type CV
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA C22.2 No. 5
• Includes mounting kit
• Product Dimensions: 7.5 in length, 5 in height, 3.5 in width

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVS2100XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVS Series
• Type : CVS
• Voltage : 240
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685705880
• GTIN : 00786685705880
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : UL 489,CSA Std. C22.2 No. 5
• Wire Size : #6 to 4/0 AWG Copper/Aluminum
