CVH2125XMM - Cutler Hammer 2 Pole 125A 240V Bolt-On Molded Case Circuit Breaker 100kAIC

CVH2125XMM

CVH2125XMM is a 2 pole, 125A, 240V bolt-on molded case circuit breaker designed for reliable power distribution and protection in commercial and industrial applications. This Cutler Hammer breaker features a thermal magnetic trip unit and is part of the CVH series, offering robust performance and easy installation. Engineered for durability, the CVH2125XMM includes a mounting kit and is rated for 100kAIC interrupt capacity. It supports wire sizes from #6 to 4/0 AWG copper or aluminum and features line and load side lug terminals for flexible wiring options. The breaker is certified to UL 489 and CSA C22.2 No. 5 standards, ensuring compliance with North American safety requirements.

• Part Number: CVH2125XMM
• Manufacturer: Cutler Hammer
• Amperage Rating: 125A
• Voltage Rating: 240V AC
• Number of Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 100kAIC
• Series/Frame: CVH
• Wire Size: #6 to 4/0 AWG Cu/Al
• Terminals: Line & Load Side Lug
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA C22.2 No. 5

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVH2125XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVH Series
• Type : CVH
• Voltage : 240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685707013
• GTIN : 00786685707013
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : UL 489,CSA Std. C22.2 No. 5
• Wire Size : #6 to 4/0 AWG Copper/Aluminum
