CSR2175N - Cutler Hammer 175 Amp 240 Volt 2-Pole CSR Frame Bolt-On Circuit Breaker

CSR2175N

CSR2175N is a Cutler Hammer 2-pole circuit breaker rated for 175 amps and 240 volts designed for bolt-on mounting.This Eaton Type CSR standard circuit breaker features a 25 kA interrupt rating at 120/240 VAC, suitable for use in Type ECC unit enclosures. It supports wire sizes from #2 AWG to 300 kcmil and carries UL 489 certification for safety and reliability.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: CSR2175N
• Amperage: 175 A
• Voltage: 120/240 V
• Poles: 2
• Frame Type: CSR
• Mounting Type: Bolt-On
• Interrupt Rating: 25 kAIC
• Wire Size Range: #2 AWG - 300 kcmil
• Certifications: UL 489
• Compatible with Type ECC Unit Enclosures
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CSR2175N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CSR Series
• Type : CSR
• Voltage : 240
• Amperage : 175
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 782113098456
• GTIN : 00782113098456
• Country of Origin : Dominican Republic
• Dimensions : 3.1 in x 3.1 in x 2 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL 489
