CSR2150N - Cutler Hammer 150 Amp 2-Pole 120/240V CSR Series Main Circuit Breaker, 25 kAIC, Plug-On, Thermal Magnetic Trip, UL 489

CSR2150N

CSR2150N is a Cutler Hammer 150 Amp, 2-pole main circuit breaker designed for reliable protection in residential and light commercial electrical panels.

This standard circuit breaker features a CSR series frame, thermal magnetic trip unit, and plug-on mounting for easy installation in Type ECC unit enclosures. It is certified to UL 489 standards and offers a robust 25 kA interrupting rating for enhanced safety.

Key Specifications
• Part Number: CSR2150N
• Manufacturer: Cutler Hammer
• Amperage: 150 A
• Voltage: 120/240 V
• Poles: 2
• Mounting Type: Plug-On
• Interrupt Rating: 25 kAIC
• Series/Frame: CSR
• Trip Unit: Thermal Magnetic
• Wire Size: #2 AWG - 300 kcmil (Aluminum/Copper)
• Certifications: UL 489
• Application: Main circuit breaker for panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CSR2150N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CSR Series
• Type : CSR
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782113098449
• GTIN : 00782113098449
• Country of Origin : United States
• Dimensions : 5.3 in x 3.52 in x 4.2 in (Length/Depth x Height x Width)
• Weight : 2.5
• Certification : UL 489
• Wire Size : 2 AWG - 300 kcmil at 60/75 deg
