CR306B004 - General Electric 18 Amp 3 Pole NEMA Magnetic Motor Starter 460-480V Coil

CR306B004

CR306B004 is a General Electric 18 Amp, 3 Pole NEMA magnetic motor starter with a 460-480 volt AC coil designed for motor control applications. This full voltage, non-reversing starter features Class 20 overload protection with manual reset.

The CR306B004 starter supports up to 5 HP at 460 volts 3-phase and includes a 3-leg overload relay to protect against overloads in all phases. It is an open enclosure type with a Size 0 frame, suitable for surface mounting. The starter is rated for 600 volts maximum system voltage and includes thermal bimetallic overload relays with Class 10/20/30 trip units. It complies with NEMA construction standards and requires separate bimetal heaters based on motor full load amps.

Key Specifications
• Amperage: 18 Amps
• Voltage: 460-480 VAC Coil, 600 VAC Max System Voltage
• Poles: 3 Pole
• Mounting Type: Surface Mount, Open Enclosure
• Interrupt Rating: NEMA Standard
• Series/Frame: CR306, Size 0
• Trip Unit: Thermal Bimetallic Overload, Class 10/20/30
• Horsepower Rating: 5 HP at 460V 3-Phase
• Overload Protection: Manual Reset
• Standards: NEMA Construction

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CR306B004
• Manufacturer : General Electric
• Brand : General Electric
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : 300-Line
• Type : CR306
• Voltage : 600
• Amperage : 18
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Horse Power : HP @ 3 Phase - 208V 3 hp HP @ 3 Phase - 240V 3 hp HP @ 3 Phase - 480V 5 hp
• Coil Voltage Maximum : 480
• Coil Voltage Minimum : 460
• Nema Rating : 0



Product Data

• UPC : 783166353905
• GTIN : 00783166353905
• Country of Origin : United States
• Dimensions : 3.71 in x 7.8 in
• Weight : 8
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA, UL Listed
