Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
CND4800T32W
CND4800T32W is a Series C molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems.This circuit breaker features a 4-pole configuration, 800A amperage rating, and a 600V AC voltage rating. It is equipped with a Digitrip 310 electronic LSI trip unit for precise overload and short-circuit protection. The breaker is 100% rated and suitable for use in a wide range of applications requiring high interrupt capacity and dependable performance.
- Manufacturer: Eaton
- Series: Series C
- Frame Type: NG
- Amperage Rating: 800 A
- Voltage Rating: 600 Vac
- Number of Poles: 4
- Interrupt Rating: 50 kAIC at 480 Vac, 85 kAIC at 240 Vac
- Mounting Type: Without terminals
- Frequency: 50/60 Hz
- Rating: 100% rated
- Trip Type: Electronic LSI
- Trip Unit: Digitrip 310
- Compliance: HACR Rated
Specifications
- Part Number: CND4800T32W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : CND
- Voltage : 600
- Amperage : 800
- Phase : 3
- Poles : 4
- AIC rating : 50kA@480V
- Connection : Bolt-On
- Functions : LSI - Long-Time, Short-Time and Instantaneous
- Frame Size : N Frame
- Protection : Solid State
Product Data
- Weight : 63
