CN15AN2AB - Cutler Hammer Freedom Series 2 Pole 9A 600V NEMA Size 00 Motor Contactor, 120V Coil, Non-Reversing

CN15AN2AB

CN15AN2AB is a Cutler Hammer Freedom Series NEMA motor control contactor designed for reliable motor starting and stopping in industrial applications.

This non-reversing, two-pole contactor features a 120V AC magnetic coil, 9A current rating, and 600V maximum voltage. It is part of the Freedom Series, NEMA Size 00, and is compatible with C306 and C396 overload relays. The unit includes one normally open auxiliary contact and uses box lug termination for secure connections.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Series: Freedom
• Type: AC Non-Reversing NEMA Contactor
• Amperage: 9A
• Voltage: 600V maximum
• Poles: 2 (NO)
• Coil Voltage: 120V AC
• Mounting Type: Panel mount (NEMA)
• Interrupt Rating: Not specified in available data
• Frame: NEMA Size 00
• Trip Unit: Not integrated (compatible with C306, C396 overload relays)
• Certifications: Not specified in available data
• Auxiliary Contact: 1NO
• Termination: Box lug

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CN15AN2AB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Freedom Series
• Type : CN15AN
• Voltage : 600
• Amperage : 9
• Phase : 3
• Poles : 2
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110

Product Data

• UPC : 782113777085
• GTIN : 00782113777085
• Country of Origin : Dominican Republic
• Dimensions : 3.49 in x 3.88 in x 1.75 in (Length/Depth x Height x Width)
• Weight : 1.1 lb
• Certification : CSA Certified,UL Listed
