CKD3250W - Eaton Series C Molded Case Circuit Breaker 250A 600V 3-Pole K-Frame

CKD3250W

CKD3250W is an Eaton Series C complete molded case circuit breaker designed for industrial power distribution and motor control applications. This K-frame breaker features fixed thermal and fixed magnetic trip protection with three-pole configuration and feed-thru connection for seamless integration into electrical panels and switchboards. CKD3250W delivers reliable circuit protection with thermal-magnetic trip technology, rated for 250 amperes at 600 volts AC and 250 volts DC. The breaker includes interchangeable long-time and instantaneous trip functions, aluminum construction, and standard interrupting capacity rated at 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. Suitable for 50/60 Hz applications, this complete breaker assembly comes with line and load side lug terminals and operates across a 40 degree C ambient temperature range.

• Manufacturer: Eaton Cutler-Hammer
• Part Number: CKD3250W
• Series: Series C
• Frame Type: K-Frame
• Poles: Three-Pole
• Amperage: 250A
• Voltage: 600 Vac / 250 Vdc
• Trip Type: Fixed Thermal and Fixed Magnetic
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Connection: Feed-Thru with Lug Terminals
• Frequency: 50/60 Hz
• Weight: 11.5 lbs
• Dimensions: 10.13 inches H x 5.5 inches W x 4.13 inches D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CKD3250W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CKD
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• Dimensions : 4.1" X 5.5" X 5.5"
• Weight : 12 lb
