CKD3200X - Eaton 200A 3-Pole 600V Molded Case Circuit Breaker Series C

CKD3200X

CKD3200X is a molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems. This breaker features a Series C design and is rated for 200A, 600V, and three poles, making it suitable for a wide range of applications. The unit is built with a K-frame and a fixed thermal and magnetic trip unit for dependable overcurrent protection. It is a complete breaker, ready for installation without additional accessories.Engineered for durability and safety, the CKD3200X is compatible with standard mounting configurations and offers a robust solution for circuit protection needs. The breaker is designed for use in systems requiring a 200A, 600V, three-pole solution with a bolt-on mounting style. It is suitable for both new installations and replacements in existing Eaton Series C panels.

• Part Number: CKD3200X
• Manufacturer: Eaton
• Series: Series C
• Frame: K-frame
• Amperage Rating: 200A
• Voltage Rating: 600 Vac, 250 Vdc
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 35 kAIC at 480 Vac
• Frequency: 50/60 Hz
• Terminals: Without terminals
• Trip Type: Fixed thermal, fixed magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CKD3200X
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CKD
• Voltage : 600
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• Dimensions : 4.1" X 5.5" X 5.5"
• Weight : 12 lb
