CHP120 - Cutler Hammer 20A 120/240V 1-Pole Thermal Magnetic Circuit Breaker 10kAIC Plug-In Type CH

CHP120

CHP120 is a Cutler Hammer 1-pole thermal magnetic circuit breaker rated for 20 amps and 120/240 volts with a 10 kA interrupt rating.This Type CHP 3/4-inch commercial circuit breaker is designed for use with Type CH loadcenters. It features a plug-in mounting style and supports wire sizes (2) #14-10 AWG Cu/Al and (1) #14-8 AWG. The breaker is UL 489 certified and HACR rated for switching duty.

Key Specifications
• Amperage: 20 A
• Voltage Rating: 120/240 V
• Number of Poles: 1
• Interrupt Rating: 10 kAIC
• Mounting Type: Plug-In
• Series/Frame: Type CH
• Trip Unit: Thermal Magnetic
• Wire Size: (2) #14-10 AWG Cu/Al, (1) #14-8 AWG
• Certifications: UL 489, HACR Rated
• Width: 3/4 inch
• Used with: Type CH Loadcenters

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CHP120
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CH Series
• Type : CHP
• Voltage : 120
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 078211393856
• GTIN : 00782113938561
• Dimensions : 3.25 in x 3.375 in x 0.75 in (Length/Depth x Height x Width)
• Weight : 0.28
