CHND412T33W - Eaton 1200A 600VAC 4-Pole NG-Frame Series C Electronic Molded Case Circuit Breaker Digitrip 310 LS Trip

CHND412T33W

CHND412T33W is an Eaton Series C electronic molded case circuit breaker designed for reliable power distribution protection.CHND412T33W features a 1200 ampere rating, 600 VAC voltage rating, and four poles in an NG-frame. It includes a Digitrip 310 RMS electronic long-time/short-time (LS) trip unit and is 80% rated. The breaker has an interrupt rating of 85 kAIC at 240 VAC and 50 kAIC at 480 VAC. It operates at 50/60 Hz frequency and comes without terminals. This complete breaker complies with HACR ratings and is part of Eaton's Series G.

Key Specifications
• Amperage: 1200 A
• Voltage Rating: 600 VAC
• Number of Poles: 4
• Frame Type: NG
• Series: Series C, Series G
• Trip Unit: Digitrip 310 RMS Electronic LS Trip
• Interrupt Rating: 85 kAIC at 240 VAC, 50 kAIC at 480 VAC
• Frequency: 50/60 Hz
• Rating: 80% rated
• Terminals: Without terminals
• Compliance: HACR Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CHND412T33W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CHND
• Voltage : 600
• Amperage : 1200
• Phase : 3
• Poles : 4
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : N Frame
• Protection : Solid State

Product Data

• Weight : 63
