CHH2225H2X - Cutler Hammer 225A 240V 2 Pole Molded Case Circuit Breaker Bolt-On

CHH2225H2X

CHH2225H2X is a Cutler Hammer molded case circuit breaker rated for 225 amps and 240 volts with 2 poles and bolt-on mounting.This circuit breaker features a thermal magnetic trip unit providing long-time and instantaneous trip protection. It is designed for 240V, 50/60 Hz applications with a 25kA interrupt rating. The breaker uses bolt-on line side connections and lug load side terminations. It belongs to the CCH series/frame and is suitable for reliable circuit protection in industrial and commercial electrical systems.

• Amperage: 225 A
• Voltage: 240 V
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 25kA @ 240V
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Frequency: 50/60 Hz
• Series/Frame: CCH
• Load Side Termination: Lugs
• Line Side Termination: Bolt-On

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CHH2225H2X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CHH Series
• Type : CHH
• Voltage : 240
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 782113032108
• GTIN : 00782113032108
• Dimensions : 4.5 in x 9.1 in x 5.3 in (Length/Depth x Height x Width)
• Weight : 4.4
