CHFEP120 - Cutler Hammer 20 Amp 1-Pole Plug-On Circuit Breaker 120/240V 10kAIC CHF Series

CHFEP120

CHFEP120 is a Cutler Hammer 20 Amp 1-Pole Plug-On Circuit Breaker designed for use in Type CH loadcenters. This breaker features a thermal magnetic trip unit and a trip flag for clear status indication. This circuit breaker is engineered for reliable protection in residential and light commercial applications. It offers plug-on mounting for easy installation and removal, and is compatible with Type CH loadcenters. The breaker includes a trip flag to visually indicate when it has tripped, aiding in troubleshooting and maintenance.

• Amperage Rating: 20 A
• Voltage Rating: 120/240 VAC
• Number of Poles: 1
• Mounting Type: Plug-On
• Interrupt Rating: 10 kAIC
• Series/Frame: CHF
• Connection Type: Thermal Magnetic Trip Unit
• Wire Size: #14-8 AWG, #14-10 AWG Cu/Al
• Requires One 3/4-Inch Space
• Switching Duty Rated
• HACR Rated
• UL 489 Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CHFEP120
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CH Series
• Type : CHFEP
• Voltage : 120
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786685627977
• GTIN : 00786685627977
• Dimensions : 7.25 in x 6.5 in x 6.75 in (Length/Depth x Height x Width)
• Weight : 3.33
• Wire Size : 14 to 6 AWG Wire
