CHFAFGF120 - Cutler Hammer 20 Amp 120 Volt 1-Pole CH Series Combination AFCI/GFCI Circuit Breaker 10 kA Interrupt

CHFAFGF120

CHFAFGF120 is a Cutler Hammer 20 Amp, 120 Volt, 1-Pole combination AFCI/GFCI circuit breaker from the CH series designed for dual arc fault and ground fault protection.This Type CH dual purpose standard circuit breaker features a plug-on mount, thermal magnetic trip unit, and a 10 kA interrupt rating. It includes a trip flag indicator LED for status, supports wire sizes from 14 to 4 AWG, and operates within a temperature range of -31 to 150 degrees Fahrenheit. The breaker is UL listed and provides complete protection for the entire circuit including homeruns, reducing installation costs by combining AFCI and GFCI functions in one device.

Key Specifications
• Amperage: 20 Amp
• Voltage: 120 VAC
• Number of Poles: 1 Pole
• Interrupt Rating: 10 kA
• Series/Frame: CH
• Mounting Type: Plug-On Mount
• Trip Unit: Thermal Magnetic
• Protection Type: Combination AFCI/GFCI
• Wire Range: 14 to 4 AWG
• Operating Temperature: -31 to 150 °F
• Certifications: UL Listed
• Trip Flag Indicator LED
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CHFAFGF120
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CH Series
• Type : CHFAFGF
• Voltage : 3
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Protection : Thermal Magnetic



Product Data

• UPC : 786670007821
• GTIN : 00786670007821
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 0.75 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.45
• Certification : Ul Listed
