CFD63B175L - Siemens 175A 600V 3-Pole Molded Case Circuit Breaker FD Frame 22kAIC

CFD63B175L

CFD63B175L is a Siemens molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a robust FD frame and is rated for 175 amps at 600 volts, making it suitable for demanding electrical environments. This Siemens CFD63B175L circuit breaker offers standard breaking capacity with a 22kA interrupt rating at 600V and 35kA at 480V. It features a bolt-on mounting design for secure installation and includes an interchangeable trip unit for flexible protection settings. The breaker is fuseless, current-limiting, and utilizes thermal magnetic technology for precise overcurrent protection. It meets UL 489 and IEC 60947-2 standards for safety and performance.

• Part Number: CFD63B175L
• Manufacturer: Siemens
• Amperage: 175A
• Voltage: 600V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 22kAIC at 600V, 35kAIC at 480V
• Series/Frame: FD
• Trip Unit: Interchangeable
• Technology: Thermal Magnetic
• Standards: UL 489, IEC 60947-2
• Application: Molded Case Circuit Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CFD63B175L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : CFD
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : FD Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 783643001237
• GTIN : 00783643001237
• Country of Origin : Mexico
• Weight : 34.061
