2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
CFD63B100L
CFD63B100L is a Siemens Sentron Series molded case circuit breaker designed for industrial and commercial power distribution applications. This 3-pole, 100-ampere breaker features thermal-magnetic trip protection with current-limiting technology and is rated for 600V AC at 50/60 Hz operation. The FD frame design provides a compact footprint while delivering robust performance and reliability in demanding electrical environments.Key Specifications
- Part Number: CFD63B100L
- Manufacturer: Siemens
- Type: CFD Sentron Series Molded Case
- Amperage: 100A
- Poles: 3
- Voltage Rating: 600V AC (50/60 Hz)
- Frame Size: FD
- Trip Function: LI (Long-Time and Instantaneous)
- Connection: Bolt-On
- Interrupt Rating: 200kA at 480V
- Temperature Rating: 40 Degrees C
- Certifications: UL 489, IEC 60947-2
Specifications
- Part Number: CFD63B100L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : CFD
- Voltage : 600
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 200kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : FD Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 783643001190
- GTIN : 00783643001190
- Country of Origin : Mexico
- Weight : 34.061
- Certification : Ul Listed
