CED63B060L - Siemens Sentron CED6 60A 600V 3-Pole Molded Case Circuit Breaker

CED63B060L

CED63B060L is a Siemens Sentron CED6 molded case circuit breaker designed for reliable low voltage circuit protection. This 3-pole breaker features a 60A current rating and is rated for 600V AC, making it suitable for a wide range of industrial and commercial applications. The CED63B060L offers extra high interrupting capacity with a rating of 200kA at 480V AC, ensuring robust protection against short circuits and overloads. It is a current limiting, fuseless breaker with a thermal-magnetic trip unit and is designed for feed-thru mounting. The unit is rated for operation at 40°C and supports wire sizes from 10 to 1/0 AWG.

• Part Number: CED63B060L
• Manufacturer: Siemens
• Series: Sentron CED6
• Amperage Rating: 60A
• Voltage Rating: 600V AC / 500V DC
• Poles: 3
• Interrupting Rating: 200kA at 480V AC
• Mounting Type: Feed-thru
• Trip Unit: Thermal-Magnetic (LI)
• Wire Size: 10 to 1/0 AWG
• Operating Temperature: 40°C
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CED63B060L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : CED
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : ED Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 783643236721
• GTIN : 00783643236721
• Country of Origin : Mexico
• Weight : 5.666
