CED63B020L - Siemens CED6 3-Pole 20A 600VAC Molded Case Circuit Breaker

CED63B020L

CED63B020L is a Siemens CED6 series molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a 20A current rating and 600VAC voltage rating, making it suitable for a wide range of applications requiring robust circuit protection. The CED63B020L utilizes a thermal/magnetic trip unit for precise overload and short-circuit protection. It is built with current limiting technology, providing a high interrupt rating of 100kAIC at 600V and 200kAIC at 480V. The breaker is designed for feed-thru mounting and is non-interchangeable for added safety. It meets UL 489 and IEC 60947-2 standards for performance and safety.

• Part Number: CED63B020L
• Manufacturer: Siemens
• Series/Frame: CED6
• Amperage: 20A
• Voltage Rating: 600VAC
• Number of Poles: 3
• Interrupt Rating: 100kAIC at 600V, 200kAIC at 480V
• Mounting Type: Feed-Thru
• Connection Type: Feed-Thru
• Trip Unit: Thermal/Magnetic
• Certifications: UL 489, IEC 60947-2
• Application: Molded Case Circuit Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CED63B020L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : CED
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : ED Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078364323668
• GTIN : 00783643236684
• Country of Origin : Mexico
• Weight : 5.512
• Certification : Ul Listed
• Wire Size : AWG 14 to AWG 10, Cu, AWG 12 to AWG 10, Al
