CED63A003 - Siemens Sentron 3A 600V 3-Pole Molded Case Circuit Breaker Bolt-On 200kAIC@480V

CED63A003

CED63A003 is a Siemens Sentron series molded case circuit breaker designed for reliable protection in commercial and industrial applications. This 3-pole breaker features a 3A current rating and is rated for 600V AC, making it suitable for a wide range of electrical systems. The CED63A003 breaker is a bolt-on type, providing secure mounting and easy installation. It offers an extra high interrupting capacity of 200kAIC at 480V and 100kAIC at 600V, ensuring robust protection against short circuits. The breaker is equipped with an instantaneous magnetic trip unit for fast response to overcurrent events. It meets UL 489 and IEC 60947-2 standards for safety and performance.

• Part Number: CED63A003
• Manufacturer: Siemens
• Series: Sentron
• Frame Type: CED
• Number of Poles: 3
• Rated Current: 3A
• Rated Voltage: 600V AC
• Mounting Type: Bolt-On
• Interrupting Rating: 200kAIC @ 480V, 100kAIC @ 600V
• Trip Unit: Instantaneous Magnetic Only
• Standards: UL 489, IEC 60947-2
• Wire Range: 14 AWG

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: CED63A003
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : CED
• Voltage : 600
• Amperage : 3
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Bolt-On
• Functions : Instantaneous Trip
• Frame Size : ED Frame
• Protection : Magnetic Only

Product Data

• UPC : 783643210912
• GTIN : 00783643210912
• Country of Origin : Mexico
• Weight : 5.82
• Wire Size : 14 to 10 AWG Copper, 12 to 10 AWG Aluminum
