Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
CE15MN3A
CE15MN3A is a Cutler Hammer Freedom Series motor control contactor rated for 105 amps and 600 volts with a 3-pole configuration.This Eaton XT IEC contactor features a steel mounting plate and operates with a coil voltage of 110-120 VAC at 50-60 Hz. It is designed for panel mounting and is part of the M-frame series, suitable for three-phase motor control applications. The contactor supports up to 10 horsepower and provides reliable non-reversing operation.
- Key Specifications
- Amperage: 105A
- Voltage: 600 VAC
- Poles: 3
- Coil Voltage: 110-120 VAC, 50-60 Hz
- Mounting Type: Steel mounting plate, panel mount
- Series/Frame: Freedom Series, M-frame
- Contact Configuration: 3NO (Normally Open)
- Non-Reversing Contactor
- Horsepower Rating: Up to 10 HP
- IEC Compliant
Additional Information
This IEC Non-Reversing Contactor includes a 110 VAC coil.
Specifications
- Part Number: CE15MN3A
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Freedom Series
- Type : CE15MN
- Voltage : 600
- Amperage : 105
- Phase : 3
- Poles : 3
- Temp Rating : -13–158 °F (-25–70 °C)
- Configuration : Non-Reversing
- Coil Voltage Maximum : 120
- Coil Voltage Minimum : 110
- Frequency : 50 Hz
Product Data
- UPC : 782113604022
- GTIN : 00782113604022
- Country of Origin : Dominican Republic
- Dimensions : 5.94 in x 7.17 in x 4.08 in (Length/Depth x Height x Width)
- Weight : 8.05 lb
- Temp Rating : -13–158 °F (-25–70 °C)
- Certification : UL Listed,IEC Rated,CSA Certified,DIN VDE 0600,ISO 9000
