CCVH2225 - Cutler Hammer 225A 240V 2 Pole Molded Case Circuit Breaker, 25kAIC, Feed-Thru, CCV Series, Type ECC Enclosure

CCVH2225

CCVH2225 is a Cutler Hammer molded case circuit breaker designed for reliable power distribution in commercial and industrial applications.

This 2-pole, 225A, 240V AC circuit breaker features a feed-thru connection, 25kA interrupt rating, and is part of the CCV series. It is suitable for use as a tenant main breaker in Type ECC unit enclosures and accepts #2/0 AWG to 300 kcmil Cu/Al conductors. The breaker is engineered for durability and safety in demanding environments.

Key Specifications

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: CCVH2225
• Amperage: 225A
• Voltage: 240V AC (120/240V)
• Poles: 2
• Mounting Type: Feed-Thru
• Interrupt Rating: 25kAIC @ 240V
• Series/Frame: CCV
• Trip Unit: Thermal-magnetic (standard)
• Certifications: UL Listed
• Conductor Range: #2/0 AWG–300 kcmil Cu/Al
• Enclosure Type: Type ECC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CCVH2225
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Tenant Main
• Type : CCVH
• Voltage : 240
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786685368672
• GTIN : 00786685368672
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL 489
• Wire Size : #2/0 AWG-300 kcmil Cu/Al
