CCVH2200X - Eaton 200A 2-Pole 120/240V CCV Tenant Main Circuit Breaker, 25kAIC Interrupt Rating

CCVH2200X

CCVH2200X is an Eaton 200 Amp, 2-pole tenant main circuit breaker designed for Type CCV frame and Type ECC unit enclosures.This circuit breaker features a 120/240 Volt rating with a 25 kA interrupt rating, suitable for residential and light commercial applications. It includes load side terminals with standard lugs compatible with copper or aluminum wiring (#2/0 AWG to 300 kcmil). The breaker is UL 489 certified and offers a limited lifetime warranty for residential use and one year for commercial use.

• Amperage Rating: 200 A
• Voltage Rating: 120/240 V
• Number of Poles: 2
• Interrupt Rating: 25 kAIC
• Frame Type: CCV
• Mounting Type: Bolt-On (Type CCV)
• Trip Unit: Thermal/Magnetic
• Wire Size Range: #2/0 AWG to 300 kcmil Cu/Al
• Certifications: UL 489
• Used With: Type ECC Unit Enclosures
• Terminals: Load side lugs
• Warranty: Limited lifetime residential, 1 year commercial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CCVH2200X
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 240
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786685368610
• GTIN : 00786685000000
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL 489
