Product Info
- Manufacturer: Cutler Hammer
- Sub-Category: Molded Case
Description
CCVH2175
The Cutler Hammer CCVH2175 is a molded case circuit breaker. This type CCVH circuit breaker is a member of The Tenant Main family. The CCVH2175 is a 2 pole, 240 Volt, 175 amp rated circuit breaker, with an AIC rating of 25kA@240V and is manufactured by Cutler Hammer. The CCVH2175 uses a feed-thru connection and includes thermal magnetic protection. Every part Essential Electric sells is also backed by our industry leading gold standard 2-year warranty.
Specifications
- Part Number: CCVH2175
- Manufacturers: Cutler Hammer
- Sub-Category: Molded Case
- UPC: 786685368542
- GTIN: 00786685368542
- Poles: 2
- Phase: 1
- Voltage: 240
- Amperage: 175
- AIC Rating: 25kA@240V
- Connection: Feed-Thru
- Protection: Thermal Magnetic
- Functions: LI - Long-Time and Instantaneous
- Wire size: #2/0 AWG to 300KCmil CU/AL
- Family: Tenant Main
- Type: CCVH
- Certification: UL
- Dimensions: Length 30.68in Height 62.18in Width 31.44in
- Weight: 3.9
